Track light for circle profile
Spot65-D9
The spot light with three different beam angles each, obtained by means of refractive or hybrid optical units. Junction arm integrated in the spotlights body to keep the barycentre aligned with the track and prevent any imbalance in possible suspension versions of track.
The junction allows 360° rotation
External dimming interface with Triac,0/1-10V,Dali,
  • Technical Specifications






    Technical drawing



    Schematic light drawing


    Beam Angle:20°

    h(m)E(lx)D(m)
    118300.26
    24570.53
    32030.80
    41141.06
    5731.33










    Main specifications

    Number of heads:1



    Lamp category:LED



    Power:8W



    CCT:2700K/3000K/4000K/5000K



    CRI:80/90



    Lumen(lm):276



    Mountings:Magnetic Track



    Environment:Indoor


    Optical

    Lighting type:Direct



    LED type:SMD LED



    Lighting distribution:Symmetric



    Optical type:Spot



    Beam angle(°)20/30/40


    Electrical

    Voltage(V):24



    Dimmable:Yes



    Driver:Remote



    Driver type:Electronic



    Emergency:Without



    Insulation class:


    Physical

    Color:Black RAL9005/white RAL9003



    Orientation:No



    Weight(kg):0.49


    Package

    Number/Ctn(kg):12



    N.W/Ctn(kg):5.9



    G.W/Ctn(kg):7.5



    L*W*H(cm):37*34*43


    Certificates



  • spot6535.jpg
