Out series
Out12
magnetic track light,belt light,UL magnetic track light,Flos magnetic lighting,Vibia plusminus - Vandolite Co.,Ltd.

  • Technical Specifications









    Technical drawing























    Schematic light drawing

    Beam Angle:34°



    h(m)E(lx)D(m)

    13060.52

    27661.05

    33401.57

    41912.10

    51222.63




















    Main specifications


    		Number of heads:12





    		Lamp category:LED





    		Power:16W





    		CCT:2700K/3000K/4000K/5000K





    		CRI:80/90





    		Lumen(lm):1000





    		Mountings:Magnetic Track





    		Environment:Indoor




    Optical


    		Lighting type:Direct





    		LED type:SMD LED





    		Lighting distribution:Symmetric





    		Optical type:Spot





    		Beam angle(°)12/34/48




    Electrical


    		Voltage(V):24





    		Dimmable:Yes





    		Driver:Remote





    		Driver type:Electronic





    		Emergency:Without





    		Insulation class:Ⅲ




    Physical


    		Color:Black RAL9005/white RAL9003





    		Orientation:No





    		Weight(kg):0.73




    Package


    		Number/Ctn(kg):10





    		N.W/Ctn(kg):7.3





    		G.W/Ctn(kg):11.5





    		L*W*H(cm):45*38.5*30




    Certificates
