Fold series
Fold32
Thanks to Fold series' interpreting another presentation of spot lighting and wall washer,
with its 90〫foldable and elegant golden cutted design, avaiable in both deep antiglare spot and opal
Minimal glare and multiple light beams
Elegent body coating and antiglare cover
External dimming interface withTriac,0/1-10V,Dali
  • Technical Specifications






    Technical drawing



    Schematic light drawing



    h(m)E(lx)D(m)
    1792.50
    2195.00
    38.87.50
    4410.00
    5312.00












    Main specifications







    Lamp category:LED



    Power:16W



    CCT:2700K/3000K/4000K/5000K



    CRI:80/90



    Lumen(lm):611



    Mountings:Magnetic Track



    Environment:Indoor


    Optical

    Lighting type:Direct



    LED type:SMD LED



    Lighting distribution:Symmetric



    Optical type:Diffuse








    Electrical

    Voltage(V):24



    Dimmable:Yes



    Driver:Remote



    Driver type:Electronic



    Emergency:Without



    Insulation class:


    Physical

    Color:Black RAL9005/white RAL9003



    Orientation:No



    Weight(kg):1.6


    Package

    Number/Ctn(kg):10



    N.W/Ctn(kg):16



    G.W/Ctn(kg):17.8



    L*W*H(cm):45*38.5*30


    Certificates


  • outlinear.jpg
